| System |
| Compression |
H.264 |
| Processor |
Cortex A9 Dual Core |
| OS |
Embedded Linux |
| Compression Standard |
H.264+ High Profile |
| Video |
| Login |
BNC * 32 |
| Exit |
VGA * 1 (1920 X 1080) /HDMI * 1 (1920 X 1080) /BNC * 1: CVBS (ana veya spot çıkış olarak kullanılır) |
| Audio / Alarm |
| Login |
RCA * 16 |
| Output |
RCA * 1 |
| 2-way audio |
1CH |
| Alarm Input |
16 Channel |
| Alarm Output |
4 Channel |
| Record |
| Resolution |
1080P,1080P lite,720P,WD1 |
| Recording speed (fps) |
1080P: 12fps / 1080P Lite / 720P / WD1: 25fps (PAL |
| Band width: |
768Kbps-8Mbps |
| Bandwidth Control: |
VBR / CBR |
| Quality: |
5 level |
| Recording Mode: |
Manual, Timed, Motion Detection |
| IP camera Input |
1080P / 720P / 960H / D1 |
| Playback |
| Playback |
16 CH |
| Search |
Time / calendar search, event (motion) |
| Smart search |
There is |
| functions |
Start, Pause, Fast Forward Forward, Digital Zoom |
| Network |
| Ethernet |
RJ45 10M / 100M adaptive Ethernet network port * 1 |
| Protocol Support |
TCP / IP, UDP, DHCP, DNS, ADSL, DDNS |
| Connection |
10 Users Online, Double Flow |
| Smart phone |
| OS |
iPhone, Android |
| functions |
Instantaneous, PTZ control (for some models) Multi-screen monitoring, device list logging |
| General |
| HDD |
Up to 64 TB with 8 SATA |
| USB |
USB2.0 × 1 (front panel), USB3.0 × 1 (rear panel) |
| Remote control |
Available |
| RS485 |
2 Pcs RS485 for PTZ and keyboard |
| Case Type |
2U |
| Dimensions |
430×453×100mm |
| Power source |
ATX |
| Consumption |
|
| Working Environment |
-10 ~ 50 ° C,% 10 ~ 90% (nem) |
