| System |
| Processor operating system |
Cortex A7 |
| compression standard |
Embedded Linux |
| Video |
|
| Login |
BNC * 4 |
| Exit |
VGA * 1 (1920 × 1080) / HDMI * 1 (1920 × 1080) |
| Sound |
| Login |
RCA * 1 |
| Exit |
RCA * 1 |
| 2-way audio |
1CH |
| Record |
| Resolution |
1080P Lite, 720P, WD1 real-time |
| Recording speed (fps) |
4ch 25fps @ 720p, 25 fps @ 1080p Lite Recording |
| Band width: |
768kbps-4Mbps |
| Bandwidth Control: |
VBR / CBR |
| Quality: |
5 level |
| Recording Mode: |
Manual, Timed, Motion Detection |
| Playback |
| Playback |
4 Channel |
| Search |
Time / calendar search, event (motion) |
| Smart search |
There is |
| functions |
Start, Pause, Fast Forward Forward, Digital Zoom |
| Network |
| Ethernet |
RJ45 10M / 100M adaptive Ethernet network port * 1 |
| Protocol Support |
TCP / IP, UDP, DHCP, DNS, ADSL, DDNS |
| Connection |
10 Users Online, Double Flow |
| Smart phone |
| OS |
iPhone, Andriod |
| functions |
Instantaneous, PTZ control (for some models) Multi-screen
monitoring, device list logging |
| General |
| HDD |
Up to 6 TB 1 SATA |
| USB |
USB 2.0 x 2 Pcs, for Mouse and for USB |
| Remote control |
Optional |
| Case Type |
1U Mini |
| Dimensions |
255 × 223 × 42 |
| Power source |
DC: 12V |
| Consumption |
<5W (without HDD) |
| Working Environment |
-10 ~ 50 ° C, 10% ~ 90% (humidity) |
