| System |
| Processor operating system |
Cortex A7 / Embedded Linux |
| compression standard |
H.264+ High Profi le |
| Video |
|
| Login |
BNC * 4 / IP Camera * 1 (6Mbps) |
| Exit |
VGA * 1 (1920 × 1080) / HDMI * 1 (1920 × 1080) |
| Sound |
| Login |
RCA * 1 |
| Exit |
RCA * 1 |
| 2-way audio |
1CH |
| Record |
| Resolution |
1080P Lite, 720P, WD1 real-time |
| Recording speed (fps) |
4ch 25fps@720p,25 fps@1080p Lite Kayıt |
| IP camera resolution |
1080P/960P/720P |
| IP camera recording speed |
25fps(PAL)/30fps(NTSC) |
| Band width: |
768Kbps-4Mbps |
| Bandwidth Control: |
VBR / CBR |
| Quality: |
5 level |
| Recording Mode: |
Manual, Timed, Motion Detection |
| Playback |
| Playback |
8 Channel |
| Search |
Time / calendar search, event (motion) |
| Akıllı arama |
There IS |
| functions |
Start, Pause, Fast Forward Forward, Digital Zoom |
| Network |
| Ethernet |
RJ45 10M / 100M adaptive Ethernet network port * 1 |
| Protocol Support |
TCP / IP, UDP, DHCP, DNS, ADSL, DDNS |
| Connection |
10 Users Online, Double Flow |
| Smart phone |
| OS |
iPhone, Andriod |
| functions |
Instant, PTZ control (for some models) Multi-display
monitoring, device list registration |
| General |
| HDD |
Up to 6 TB 1 SATA |
| USB |
USB 2.0 x 2 Pcs, for Mouse and for USB |
| Remote control |
Optional |
| Case Type |
1U Mini |
| Dimensions |
255×223×42 |
| Power source |
DC: 12V |
| Consumption |
< 5 W (Without HDD) |
| Working Environment |
-10 ~ 50 ° C, 10% ~ 90% (humidity) |
