| Video / Audio Input |
| Audio input: |
16 channels |
| Video compression: |
H.265 + / H.265 / H.264 + / H.264 |
| Analog and HD-TVI video input: |
16-ch, BNC interface (1.0Vp-p, 75 B) connection |
| Supported camera types: |
HDTVI girişi: 5MP, 4MP, 3MP, 1080P / 25Hz, 1080P / 30Hz, 720P / 25Hz, 720P /
30Hz, 720P / 50Hz, 720P / 60Hz,
AHD girişi: 1080P / 25Hz, 1080P / 30Hz, 720P / 25Hz, 720P / 30Hz
CVI girişi: 1080P / 25Hz, 1080P / 30Hz, 720P / 25Hz, 720P / 30Hz
CVBS girişi |
| Video Input Interface |
BNC (1.0 Vp-p, 75Ω) |
| Audio compression: |
G.711u |
| Audio input interface: |
4 ch, RCA (2.0 Vp-p, 1 KΩ) |
| Two way audio: |
1-ch, RCA (2.0 Vp-p, 1 K 1), (using channel 1 of the audio input) |
| Video / Audio Output |
| CVBS Output: |
1-ch BNC (1.0Vp-p 75Ω), çözünürlük PAL: 704x576, NTSC: 704x480 |
| HDMI / VGA Output: |
VGA: 1-ch, 1920 × 1080 / 60Hz, 1280 × 1024 / 60Hz, 1280 × 720 / 60Hz,
1024 × 768 / 60Hz
HDMI: 1-ch 1920 × 1080 / 60Hz, 1280 × 1024 / 60Hz, 1280 × 720 / 60Hz,
1024 × 768 / 60Hz |
| Recording resolution: |
5 MP / 4 MP / 3 MP / 1080p / 720p / WD1 / 4CIF / VGA / CIF |
| Square |
Main stream: 5 MP @ 12fps / 4 MP @ 15fps / 3 MP @ 18fps
1080p / 720p / WD1 / 4CIF / VGA / CIF @ 25fps (P) / 30fps (N)
Downstream: WD1 / 4CIF / CIF @ 25fps (P) / 30fps (N) |
| Video Bit Rate: |
32 Kbps ~ 10 Mbps |
| Flow type: |
Video / Video and Audio |
| Two way audio: |
1-ch, RCA (2.0 Vp-p, 1 k V) (using audio input) |
| Audio output: |
1-ch RCA (Linear, 1k ch) |
| Audio Bit Rate: |
64kbps |
| Double flow: |
supports |
| Playback resolution |
5MP / 4MP / 3MP / 1080p / 720p / VGA / WD1 / 4CIF / CIF / QVGA / QCIF |
| Synchronized Playback: |
16 Channel |
| Network Management |
| Remote connection: |
128 |
| Network protocols: |
TCP / IP, PPPoE, DHCP, Hik-connect Bulut P2P, DNS, DDNS, NTP, SADP, NFS,
iSCSI, UPnP ™, HTTPS, ONVIF |
| Hard Disk Drive |
|
| HDD: |
2 SATA |
| Capacity: |
Up to 8 TB capacity per drive |
| External Interface |
| Network Interface: |
10M / 100M / 1000M self-adaptive Ethernet interface |
| USB interface: |
1 USB 2.0 ve 1 USB 3.0 |
| RS-485: |
1 Piece |
| Alarm input: |
16 Channel |
| Alarm output: |
4 CH |
| General |
| Power source: |
DC 12V |
| Consumption: |
≤ 25W (hard diskless) |
| Operating temperature |
-10 ºC ~ + 55 ºC |
| Operating Humidity: |
% 10 -% 90 |
| Dimensions: |
380 × 320 × 48 mm |
| Weight: |
2 Kg |
