| Camera Features |
| Image sensor: |
1 / 2.8 2.8 CMOS |
| Effective Pixels: |
1920x1080 |
| Electronic Shutter Speed |
1 / 25s ~ 1 / 100000s |
| Lens Type |
M12Sound Iris |
| Minimum Lighting |
0.1 lux @ F1.2, AGC open, 0 lux (IR ON) |
| Lens |
2.8 mm |
| Day Night Mode |
ICR Available |
| WDR: |
Digital WDR |
| Noise Reduction |
3D DNR |
| Compression Standard |
H.264 + Beginner Profi / Master Profi / High Profi |
| Resolution |
1080P (1920 x 1080), 720P (1280 x 720), D1, CIF, 480 x 240 |
| Main current |
60Hz: 1080P (1 ~ 30fps) / 720P (1 ~ 30fps) 50Hz: 1080P (1 ~ 25fps) / 720P (1 ~ 25fps) |
| Bit Rate |
256Kbps ~ 5Mbps |
| Code Mode |
VBR / CBR |
| Quality |
Five levels below the VBR; Freely adjustable under CBR |
| Image Settings |
ROI, Saturation, Brightness, Chrome, Contrast, Wide Dynamic, Sharpen, NR, etc. Can be adjusted |
| ROI |
3 ROI |
| interfaces |
| Network |
RJ45 |
| Functions |
| Remote monitoring |
IE scan, CMS remote control |
| Online Connection |
Simultaneous monitoring. Supports multi-stream streaming |
| Network Protocol |
TCP / IP, UDP, DHCP, NTP, RTSP, DDNS, SMTP, FTP |
| Interface Protocol |
ONVIF |
| Storage |
Network remote storage |
| Smart alarm |
Motion alarm |
| PoE |
There is |
| IR Distance |
20 m |
| Waterproofing certificate |
IP66 |
| General |
| Power source |
DC12V / PoE |
| Power consumption |
|
| Working environment |
108 87 * 108mm |
| Weight |
369 g |
| Setup |
Ceiling installation, Wall mounting with Bracket |
