| Camera Features |
| Görüntü sensörü: |
1 / 3 “CMOS |
| Effective Pixels: |
2592 x 1520 |
| Electronic Shutter Speed |
1 / 25s ~ 1 / 100000s |
| Lens Type |
M12Sabit İris |
| Minimum Lighting |
0.05 lux @F1.2, AGC açık,0 lux (IR ON) |
| Lens |
3.6 mm @ F1.6 |
| Day Night Mode |
ICR Mevcut |
| WDR: |
Digital WDR |
| Noise Reduction |
2D/3D DNR |
| Video sıkıştırma |
H.265 / H.264 / MJPEG |
| H.265+Sıkıştırma Standardı |
Main Profi le @Leve4.1 High Tier |
| Resolution |
4MP ( 2592x1520 ), 2K ( 2560x1440 ), 3MP ( 2304x1296 ), 3MP ( 2048x1536 ), 1080P
( 1920x1080 ), 720P ( 1280x720 ), D1, CIF, 480x240 |
| Ana akım |
60Hz : 4MP( 1 ~ 30fps ) / 2K( 1 ~ 20fps ) / 3MP / 1080P (1 ~ 30fps) / 720P (1 ~ 30fps)
50Hz: 4MP( 1 ~ 0fps ) / 2K( 1 ~ 20fps ) /3MP / 1080P (1 ~ 25fps) / 720P (1 ~ 25fps) |
| Bit Oranı |
128Kbps ~ 8Mbps |
| Code Mode |
VBR / CBR |
| Kalite |
VBR altındaki beş seviye; CBR altında serbestçe ayarlanabilir |
| Resim Ayarları |
ROI, Saturation, Brightness, Chrome, Contrast, Wide Dynamic, Sharpen, NR, etc. Can be adjusted through client software or web browser |
| ROI |
Each ROI will be configured separately |
| interfaces |
| Network |
RJ45 |
| Sound |
MIC IN x 1 |
| Fonksiyonlar |
| Uzaktan gözlemleme |
IE scan, CMS remote control |
| Online Connection |
Simultaneous monitoring support for up to 4 users; Supports multi-stream streaming |
| Network Protocol |
TCP / IP, UDP, DHCP, NTP, RTSP, DDNS, SMTP, FTP |
| Interface Protocol |
ONVIF |
| Storage |
Network remote storage |
| Smart alarm |
Motion alarm |
| Akıllı Analiz |
Field violation, Motion detection, Line crossing violation, Sabotage etc. |
| PoE |
There İs |
| IR Mesafe |
30 m |
| Waterproofing certificate |
IP66 |
| General |
| Güç kaynağı |
DC12V / PoE |
| Power consumption |
<2,5 W , 6W (IR Açık) |
| Çalışma ortamı |
-20 ° C ~ 50 ° C, 10% ~ 90% humidity |
| Dimensions |
Φ 87 * 219 mm |
| Ağırlık |
595 gr |
| Setup |
Duvara montaj, Tavana montaj |
