| System |
| Processor operating system |
Cortex A7 /Gömülü Linux |
| compression standard |
H.264 + High Profile |
| Video |
|
| Login |
BNC * 8 |
| Exit |
VGA * 1 (1920 × 1080) / HDMI * 1 (1920 × 1080) / BNC * 1: CVBS (used as main or spot output) |
| Video |
| Login |
BNC * 4 |
| IP input / Access Bandwidth |
1 Pcs Rivo IP Camera |
| Exit |
VGA * 1 (1920 X 1080) / TV / HDMI * 1 (1920 X 1080) / BNC * 1: CVBS (used as main or spot output) |
| Audio / alarm |
| Audio Input |
RCA * 4 |
| Audio Output |
RCA * 1 |
| 2-way audio |
1CH |
| Alar Introduction |
4 Kanal |
| Alarm output |
1CH |
| Record |
| Resolution |
1080P,1080P lite,720P,WD1 |
| Recording speed (fps) |
1080P: 12fps / 1080P Lite / 720P / WD1: 25fps (PAL) |
| IP camera Input |
1080P / 720P / 960H / D1 |
| Band width: |
768Kbps-8Mbps |
| Bandwidth Control: |
VBR / CBR |
| Quality: |
5 Level |
| Recording Mode: |
Manuel, Zamanlı, Hareket Algılama |
| Playback |
| Playback |
8 CH |
| Search |
Time / calendar search, event (motion) |
| Smart search |
Yes |
| functions |
Start, Pause, Fast Forward Forward, Digital Zoom |
| Network |
| Ethernet |
RJ45 10M / 100M adaptive Ethernet network port * 1 |
| Protocol Support |
TCP / IP, UDP, DHCP, DNS, ADSL, DDNS |
| Connection |
10 Kullanıcı Online, Çift Akışlı |
| Smart Phone |
| OS |
iPhone, Andriod |
| functions |
Instant, PTZ control (for some models) Multi-display
monitoring, device list registration |
| General |
| HDD |
Up to 8 TB 1 SATA |
| USB |
USB 2.0 x 2 Pcs, for Mouse and for USB |
| Remote control |
Optional |
| RS485 |
RS485 for PTZ and Keyboard |
| Case Type |
1U |
| Dimensions |
300×248×52mm |
| Power source |
DC: 12V |
| Consumption |
|
| Working Environment |
-10 ~ 50 ° C, 10% ~ 90% (humidity) |
