Model numarası.
|
KD-HA80AC84-P
|
|
|
Sensor
|
1/3 "Panasonic CMOS sensor
|
|
Solution
|
HD: 1920x1080 (30fps / 25fps); Analog: 700TVL
|
|
S / N
|
50 dB (AGC Off)
|
|
Zoom Rate
|
30x optik zoom 32x dijital zoom
|
|
|
Focal length
|
f = 4.3 (Wide) -129 (Tele) mm
|
|
|
Iris
|
F = 1.6 (Geniş) -5.0 (Tele)
|
|
|
Mini Lighting
|
Color Mode: 0.5 lux / B: 0.2lux; Color DSS Mode: 0.001 lux / B DSS: 0.0004lux
|
|
Day and night
|
Auto / Night / Daytime
|
|
Focus
|
Automatic / Manual / Semi-Automatic
|
|
Iris Setting
|
Automatic / Manual
|
|
Shutter speed
|
Automatic (x128 ~ 1/50 sec ~ 1/120000 sec.)
|
|
WDR
|
/ HLC On / WDR On Off
|
|
AGC
|
On off
|
|
White balance
|
Auto / On / Off / ATW / Manual
|
|
DNR
|
On / Off / DNR On
|
|
Brightness
|
1-14
|
|
Pan / Tilt Range
|
Horizontal 360 ° (infinite) / Vertical: 0-90 °
|
|
Speed
|
0 ~ 180 ° / sec. (To zoom the proportional ratio)
|
|
Önceden ayarlanmış
|
254
|
|
Auto scan
|
8
|
|
Model
|
4
|
|
Group
|
8
|
|
Program
|
16
|
|
Defogger
|
Support
|
|
Auto Flip
|
On off
|
|
Power Up Action
|
None / Last Action / Preset / Pattern / Scan / Group
|
|
Parking Action
|
None / Last Action / Preset / Pattern / Scan / Group
|
|
Zoom Proportional
|
On off
|
|
Alarm I / O
|
8CH Alarm input 4CH Alarm
|
|
Contact
|
RS-485
|
|
Protokol
|
Pelco D / P Automatic identification
|
|
Privacy zone
|
8
|
|
Input voltage
|
24VAC / DC12V
|
|
Irradiation distance
|
100m
|
|
Infrared mode
|
Automatic / Manual / Semi-Automatic
|
|
Led layout
|
9.Near for Array IR LEDS: 3; Moderate: 3; Remote: 3.
|
|
LED Power
|
Max3W
|
|
Brightness level
|
ON OFF
|
|
Sensitivity
|
-10 ~ 10
|
|
Led current
|
2.5A
|
|
Max. Power consumption
|
DC12V: 26W AC24V: 65W
|
|
Extra Power Supply
|
DC12V / 500mA
|
|
Size
|
Φ226mm * 428Hmm;
|
|
Weight
|
3.9kg
|
|
Operating temperature.
|
-10 ° C ~ + 50 ° C;
|
|
Protection class
|
IP65; TVS 6000V protection, anti surge protection in accordance with GB / T 17626.5.4 standard
|
|
Working Humidity
|
% 0 ~% 90 (Non-yoğunlaşma)
|
