Model
|
KD-D2832N-P
|
|
|
|
Special function
|
|
P2P function
|
Available
|
|
Cloud storage
|
Support Dropbox and Google Drive
|
|
Bi-directional Speech
|
Two-way audio intercom function
|
|
Motion detection
|
Regions: 396 (22 * 18) Accuracy: 1 ~ 6 (level 6 highest)
|
|
Image Capture
|
Support Capture JPEG
|
|
System
|
|
OS
|
Embedded LINUX
|
|
Basic function
|
Live monitoring record playback backup and remote access
|
|
Hardware Solutions
|
Quad-core embedded processor
|
|
Video and audio input
|
|
Bi-directional Speech
|
1CHBNC (Hat in2Vp-p1Kohms)
|
|
Incoming bandwidth
|
200Mbps
(Up to 32CH 1080P @ 6M)
|
|
|
|
IPC Input
|
32CH
|
|
|
|
Video and Audio output
|
|
VGA
|
1CH1920 × 10801280 × 10241280 × 7201024 × 768
|
|
HDMI
|
3840 × 2160,1920 × 10801280 × 10241280 × 7201024 × 768
|
|
Ses çıkışı
|
1CHBNC (Hat out2Vp-p300ohms)
|
|
Video and Audio encoding
|
|
Audio Compression
|
G.711A
|
|
Audio bit rate
|
64kbps
|
|
Video and Audio decoding
|
|
IP Channel Resolution
|
Main current: up to 5632 × 4224
Auxiliary current: D1
|
|
Video decoding
|
H.265 (Main Profile@L5.0 High tie) /H.264 (Up to High Profile@Level5.0)
|
|
Audio decoding
|
G.711A / G.726
|
|
Sync Playback
|
Up to 32CH
|
|
|
|
Decoding ability
|
16CH 1080P @ 30fps
|
|
Hard disk
|
|
SATA
|
8 SATA interfaces
|
|
E SATA
|
1 eSATA interface
|
|
Max Capacity
|
Unlimited
|
|
Auxiliary Interface
|
|
Network Interface
|
2 RJ45 10M / 100M / 1000M self-adaptive Ethernet interfaces
|
|
USB
|
2 USB2.0 Interfaces
|
|
Alarm Input
|
16CH; On / Off Relay
|
|
Alarm Output
|
4CH; NO / NC
|
|
RS-232
|
1 RS-232 interface
|
|
RS-485
|
1 RS-485 interface
|
|
General
|
|
Power source
|
110V ~ 220V% 10 47-63Hz ±
|
|
Power consumption
|
20W (excluding HDD)
|
|
Working environment
|
0 ℃ - + 55 ℃
|
|
Working Humidity
|
% 90 -% 10
|
|
Size
(W × D × H)
|
2U 520 * 520 * 215mm
|
|
Weight
|
7KG (excluding HDD)
|
|
Setup
|
Rack Mount Desktop Installation
|
