| Camera |
| Image sensor: |
1/3 amalı Progressive Scan CMOS |
| Number of active pixels: |
1920 (H) x1080 (V) |
| Signal: |
PAL / NTSC |
| Minimum Lighting |
F1.6, AGC Outdoor: Color: 0.05 lux, B / W: 0.01lux, 0 luxury with IR |
| White Balance: |
Auto / Manual / ATW / Off / On / Daylight lamp |
| AGC: |
Automatic / Manual |
| BLC: |
ON OFF |
| HLC: |
supports |
| Smart Defog |
supports |
| WD |
120 dB |
| Shooting Time |
1-1 / 10,000s |
| Day and night |
UPPER |
| Digital zoom |
16X |
| Privacy Masking |
2pcs privacy mask programmable |
| Autofocus |
Automatic / Semi-Automatic / Manual |
| Lens |
| Focal Length: |
4.3-129 mm, 30x |
| Zoom Speed: |
Approx. 3s (Optical Wide Tele) |
| Perspective: |
65.5-2.11 degree (Wide Tele) |
| Min. Working Distance |
10-1,500mm (Wide Tele) |
| Aperture range :: |
F1.6 - F5.0 |
| Pan & Tilt |
| Pan Range |
360 ° infinity |
| Pan speed:: |
Pan Manual Speed: 0.1 ° -160 ° / s,
Pan Preset Speed: 240 ° / s |
| Tilt Range :: |
-15 ° -90 ° (Automatic Flip) |
| Tilt Speed :: |
Tilt Manual Speed: 0.1 ° -120 ° / s,
Tilt Preset Speed: 200 ° / s |
| Proportional Zoom: |
Rotation speed can be adjusted automatically according to zoom levels |
| Number of Presets :: |
300g |
| Patrol: |
8 patrols with up to 32 presets per patrol |
| Power loss recovery: |
Support |
| Park Action: |
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan /
Frame scan / Panorama scan |
| PTZ position indicator: |
On off |
| Freeze Frame: |
supports |
| Infrared |
| Night Vision: |
150 |
| Alarm: |
|
| Alarm input :: |
2nd |
| Alarm output: |
one |
| Alarm actions: |
Preset, Patrol, Pattern, Record, Relay output, Download center, FTP upload, e-mail |
| Input Output |
| Audio input: |
1
Line input in Mic in / Line interface : 2-2.4V [pp]; Output impedance: 1K:, ± 10% |
| Audio output: |
1 Audio output interface Line level, impedance: 600 Ses |
| Network |
| Ethernet: |
10Base -T, / 100Base-TX, RJ45 Connector |
| Resolution: |
1920 × 1080 |
| Main Transfer: |
50Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720), 50fps (1280 × 960, 1280 × 720);
60Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720), 60 fps (1280 × 960, 1280 × 720) |
| Bottom Flow: |
50Hz: 25 fps (704 × 576, 640x480, 352 × 288); 60Hz: 30 fps (704 × 480, 640x480, 352 × 240) |
| Third Transfer :: |
50Hz: 25 fps (1920 x 1080, 1280 × 960, 1280 × 720, 704 × 576, 640x480, 352 × 288)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640x480, 352 × 288) |
| Video compression :: |
H.265 + / H.265 / H.264 / MJPEG |
| ROI: |
Support 2 areas with adjustable level |
| Audio compression: |
G.711ulaw / G.711alaw / G.726 / MP2L2 |
| Concurrent Users :: |
Up to 20 users |
| Double flow :: |
supports |
| Internal Storage :: |
128GB Micro SD / SDHC / SDXC |
| Security precautions: |
User authentication (ID and PW), host authentication (MAC address) |
| Hike-Connect :: |
Support |
| Cilent GUI |
| Camera control :: |
Scroll / Tilt, Zoom, Focus, Centering, Mouse dragging zoom, Iris, preset
search and programming, auto mode |
| Date and Time Display: |
Time: Week: Date, 6 formats on the client |
| Client: |
IVMS-4200 support |
| Internet browser: |
IE 7+, Chrome 18 - 42, Firefox 5.0 +, Safari 5.02 + |
| General |
| Menu Language: |
English |
| Power source: |
AC 24V and Hi-PoE |
| Power consumption: |
Max. 40W |
| Working temperature / humidity: |
-30 ° C -65 ° C 90% Humidity |
| Protection Certificate: |
IP66, TVS 4,000V lightning protection, overvoltage protection and voltage transient protection |
| Assembly: |
Various optional mounting modes |
| Dimensions: |
.4220 × 353.4mm |
| Weight: |
4.5kg (9.92Ibs) |
| Mounting option: |
Long-arm wall mounting: DS-1602ZJ; Corner mounting: DS-1602ZJ-corner; Mast Mount: DS-1602ZJpole;
Power box assembly: DS-1602ZJ-box |
